M5 x 13mm Metal Type D Nuts | Zinc

The M5 x 13mm Type D Flanged Insert Nut is a high-performance self-tapping threaded insert designed to create strong, permanent metric threads in timber, MDF, plywood, particleboard, chipboard and other engineered wood materials. Manufactured from durable zinc alloy die-cast, these threaded inserts provide excellent pull-out resistance while delivering a reliable metal thread for repeated assembly and disassembly.

The aggressive external self-tapping thread cuts directly into the material during installation, eliminating the need for adhesives or specialist fixing methods. The integral flange prevents over-insertion and helps protect decorative or laminated surfaces from splitting or damage during installation.

Ideal for both production environments and repair work, Type D insert nuts are widely used across furniture manufacturing, cabinetry, shop fitting and commercial joinery.

Key Features & Benefits

• Manufactured from high-quality zinc alloy die-cast
• Metric M5 internal thread
• 13mm installation depth
• Self-tapping external thread for quick installation
• Flanged design prevents over-driving
• High resistance to pull-out and vibration
• Creates a permanent, reusable metal thread in wood
• Suitable for repeated assembly without damaging the base material
• No adhesive required
• Ideal for production, maintenance and furniture repair

Technical Specification

• Thread Size: M5
• Insert Length: 13mm
• Material: Zinc Alloy Die Cast
• Finish: Zinc
• Style: Type D
• Head Type: Flanged
• Installation: Self-Tapping
• Suitable Materials: Solid Timber, MDF, Chipboard, Particleboard, Plywood, Hardwood, Softwood

Applications

M5 Type D insert nuts are commonly specified where a durable machine thread is required within wooden components.

Typical applications include:

• Furniture manufacturing
• Flat-pack furniture
• Kitchen cabinets
• Office desks
• Shop fittings
• Display units
• Exhibition stands
• Educational furniture
• Commercial joinery
• Storage systems
• Timber assemblies
• Repair and refurbishment projects

Why Choose Type D Flanged Insert Nuts?

Unlike conventional wood screws, Type D threaded inserts create a permanent metal thread that can withstand frequent removal and refitting of machine screws without degrading the surrounding material.

The external self-tapping thread provides exceptional holding power, while the flange distributes installation forces across the surface, reducing the likelihood of material damage. This makes Type D insert nuts particularly suitable for applications subject to vibration, repeated maintenance or regular disassembly.

Available Sizes

Our range of flanged insert nuts are available in additional thread sizes and lengths to suit different timber thicknesses and application requirements. If you require a size or specification not shown online, please contact our technical sales team for availability.
